  7. DDA800 RCD BLOCK 2P 100A 30MA
  • (0)
ABB

DDA800 RCD BLOCK 2P 100A 30MA

2CSB802401R1000
2159323

Sign in to view price

The RCD Block DDA800 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications. This product provides the best compromise between safety and continuity in the service, thanks to the resistance to unwanted trippings. It is suitable for assembly with MCBs S800 series up to 100A.
abb-2csb802401r1000
  • All returns must be made within 7 days of purchase.
  • Valid receipt is required for all returns.
  • Click Here to view the return policy.
Available Shipping Methods:

Product Overview

Product ID:
2159323
Manufacturer Part Number:
2CSB802401R1000
EAN:
8012542544630
Brand/Manufacturer
ABB
Unit of Measure:
PCS

Specification

Ambient temperature during operating:
-25...60 °C
Anti-nuisance tripping version:
yes
Connectable conductor cross section multi-wired:
6...50 mm²
Connectable conductor cross section solid-core:
6...70 mm²
Degree of protection (IP):
IP2X
Delay adjustable:
no
Frequency:
50/60 Hz
Leakage current type:
A
Max. delay time:
0 ms
Nominal current:
100 A
Nominal voltage:
230...230 V
Number of poles:
2
Rated fault current:
0.03...0.03 A
Rated fault current adjustable:
no
Rated impulse withstand voltage Uimp:
6 kV
Rated insulation voltage Ui:
690 V
Surge current capacity:
3 kA
With interlocking device:
no
